Recently one of our blog readers raised this question that there are some errors when buying a used slot machine. Though his query was related to his IGT Double Diamond model 96435800 reel slot machine which he had bought but here we are catering to some of the most common errors buyers face when they buy a real slot machine specially a refurbished ones. You can try to fix these errors by doing the following actions as given against each error. Also there are many superb videos online that teach you how to fix these errors.

EEPROM Device Error

EEPROM (electrically erasable programmable read-only memory) is user-modifiable read-only memory (ROM) that can be erased and reprogrammed (written to) repeatedly through the application of higher than normal electrical voltage. Unlike EPROM chips, EEPROMs do not need to be removed from the computer to be modified. However, an EEPROM chip has to be erased and reprogrammed in its entirety, not selectively. It also has a limited life – that is, the number of times it can be reprogrammed is limited to tens or hundreds of thousands of times. In an EEPROM that is frequently reprogrammed while the computer is in use, the life of the EEPROM can be an important design consideration.

A special form of EEPROM is flash memory, which uses normal PC voltages for erasure and reprogramming.

Here is the video how to fix this error

Error on door of slot machine

This is the most common error that new slot machine owners will have because the cash out button was pushed and the number of coins in the hopper is less than the total credits to be paid out. You can open the main door and check the hopper for coin level (your hopper will not dispense all of the coins), refill and close the main door. Coin Hopper – This bucket contains all coins accepted by the machine and pays out those coins when you choose to cash out. For machines where the ticket printer is enabled, the hopper won't pay out and will instead simply collect coins. Hoppers are necessary for all coin-enabled machines.

Many times when the display on the door indicates an error condition, open and close the door to reset the game and clear the error. Open the main door which clears the current game information and a “0” appears in the Coins Played window. Closing the door resets the game and the reels will spin and stop in their last valid position. The error code should clear and the digital display returns to normal game play.

Error Code 12 Battery Voltage

To fix this error turn power off and then turn power on if the battery voltage has dropped below 2.9 V. Also replace ASAP due to possible RAM (Memory) corruption. Open / close door to clear and also Replace 3.6 V Lithium battery on CPU board.

Coin Errors

For coin errors see that comparitor is seated in all four acceptor clips and that acceptor does not have coin(s) jammed or the coin optics below comparitor is not blocked You can ensure toggle power switch is in activated position if installed.

Coin Out Tilt Hopper

Check for and clear any jammed coins in the coin out channel. Also see that the coins are not jammed behind hopper knife or see that the coin out optic sensor is not blocked by dust. If so you can replace hopper coin out optic.

Igt Slot Machine Coin Hopper Machine

Error in Extra Coin Out Hopper

To fix this see that the hopper motor brake functions properly. Check the coin wiper/ knife for jams and if so adjust them if necessary.

Hopper Empty Error

This is the most common error that new slot machine owners will have because the cash out button was pushed and the number of coins in the hopper is less than the total credits to be paid out. You can open the main door and check the hopper for coin level (your hopper will not dispense all of the coins), refill and close the main door. You may have to do this several times for all of the credits to be paid out.

Reel Tilt Errors

You will find that there are reel tilt errors and for this see that whether the designated reel is misaligned or malfunctioning. Also check if the reel is not unplugged. You can switch connectors from one reel to another, determine if error follows change of connectors. Try replacing reel assembly or optics if error stays with bad reel. Also clear Ram and see if it works again.

Error Codes and Fixes

Igt Slot Machine Coin Hopper Parts

During the process of clearing error codes, you may encounter multiple 6x series errors. Here are few common ones and their fixes

CMOS RAM Error

Igt Slot Machine Coin Hopper Price Guide

This means Bad (or cleared) CMOS RAM data You can Press test button 3 seconds Error code 61-1 should now be displayed. Now close door, turn and release reset key once. Same for game data reset.

Bad Game EPROM or Data EPROM Error

Check circuit board and replace Game EPROM. For Data EPROM error check circuit board and replace Reel EPROM

Bad EPROM Device or Bad EPROM Data or Game Type Mismatch

Igt Slot Machine Coin Hopper

Press self test switch for 3 seconds If error will not clear replace EPROM Also if the processor could not read or write to the named chip Press test button for 3 seconds Error code clears from display.

Igt Slot Machine Coin Hopper Collectors

Igt slot machine coin hopper parts

Most of the errors can be resolved with little help but many need technical knowledge. Remember that if you are on a warranty or not the place or online site where you purchased a used slot machine is there to assist you with trouble shooting and repairs. They can guide you over the phone or send some mechanical and technical person to do so.

Support VoyForums
VoyForums Announcement: Programming and providing support for this service has been a labor of love since 1997. We are one of the few services online who values our users' privacy, and have never sold your information. We have even fought hard to defend your privacy in legal cases; however, we've done it with almost no financial support -- paying out of pocket to continue providing the service. Due to the issues imposed on us by advertisers, we also stopped hosting most ads on the forums many years ago. We hope you appreciate our efforts.

Show your support by donating any amount. (Note: We are still technically a for-profit company, so your contribution is not tax-deductible.) PayPal Acct: Feedback:

Igt slot machine coin hopperIgt Slot Machine Coin Hopper

Donate to VoyForums (PayPal):

[ Login ] [ Contact Forum Admin ] [ Main index ] [ Post a new message ] [ Search Check update time Archives:1, 2, 3, [4], 5, 6, 7, 8, 9, 10 ]
Subject: Clearing IGT 3300 code without filling the hopper

Author:
John Schmidt
[ Next Thread Previous Thread Next Message Previous Message] Date Posted:08:07:27 11/05/06 Sun
Is it possible to clear a 3300 code on an IGT w/o filling the hopper?
[Next Thread Previous Thread Next Message Previous Message]
Igt
Replies:
[> Subject: Re: Clearing IGT 3300 code without filling the hopper

Author:
jay
[ Edit View ]
Date Posted:06:28:44 11/06/06 Mon
I am doubtful that this is possible.
If you have a 3300 then the S+ is trying to complete a payout sequence. You would - refill, let it continue its payout and refill again until it is complete.
There are a couple of techniques for avoiding this situation.
1. Remove the wire feeding your cash/credit button. If you can't cashout you can't get a 3300 error. Make sure you have your game set to have all pays go to credits 5-1 on most chips. Set your max credits to 9998 (there is a problem with 9999).
2. If you don't like the idea above, Set your max hopper pay to 1. This will cause the machine to spit out one coin then the machine will lock up into 'hand pay'. You simply turn the reset key and the machine will count down the pay on the LED windows, reset it self and continue. You will note that most of the machines will say Max Hopper Pay 400 or 1000 on the reel glass, this is the same thing but smaller.
Note it is not possible to make any of these settings changes until you have 0 credits on the machine.
>Is it possible to clear a 3300 code on an IGT w/o
>filling the hopper?
